Deck Springs,Bell Cranks,Guide

Hydro Belt Spring For Bad Boy

Hydro Belt Spring replaces Bad Boy 034-9000-00. Fits 2012-2017 Stand-on, 2019-2023 Renegade, 2013-2016 ZT Elite, 2007-2012 ZT and 2010-2015 CZT.Dimensions:LENGTH: 4-7/50"WIRE DIAMETER: 21/200"COIL DIAMETER: 3/4"

Brake Return Spring For Bad Boy

Brake Return Spring replaces Bad Boy 034-1026-00. Fits 2021-2023 Maverick, 2022-2023 Maverick HD, 2021-2023 ZT Elite, 2023 ZT Elite Limited, 2021-2023 ZT Avenger.Replaces:BAD BOY 034-1026-00Dimensions:LENGTH: 4-12/25"WIRE DIAMETER: 9/125"COIL DIAMETER:...

Brake Spring For Bad Boy

Extension Brake Spring replaces Bad Boy 034-1025-00. Fits 2016-2023 Maverick, 2019-2023 Renegade, 2019-2023 Rebel, 2020-2023 Revolt, 2019-2023 Rogue, 2016-2020 Compact Outlaw.Replaces:BAD BOY 034-1025-00Dimensions:LENGTH: 5-7/50"WIRE DIAMETER: 9/125"COIL...

Deck Spring For Bad Boy

Deck Spring replaces Bad Boy 034-2030-00. Fits 2019-2023 Renegade, Rebel, Revolt and Rogue.Replaces:BAD BOY 034-2030-00Dimensions:LENGTH: 10-47/50"WIRE DIAMETER: 187/1000"COIL DIAMETER: 1-13/50"

Spring W/Loop Stiga (Export)

Spring with Loop. Fits Stiga. (Export Only)Replaces:STIGA 1134-1322-01Dimensions:DIAMETER: 3/4"THICKNESS: 7/64"OVERALL LENGTH: 9"LENGTH OF COIL: 3-61/64"CASE QTY: 75PALLET QTY: 48

Brake Spring Stiga (Export)

(Export Only) Spring fits Stiga.Replaces:STIGA 1134-1242-02Dimensions:DIAMETER: 41/64"THICKNESS: 1/8"OVERALL LENGTH: 3-9/64"LENGTH OF COIL: 1-51/64"CASE QTY: 100PALLET QTY: 60

Deck/Pump Spring For Bad Boy

Deck/Pump Spring replaces Bad Boy 034-2009-00, 034-2020-00, 034-5039-00.Replaces:BAD BOY 034-2009-00BAD BOY 034-2020-00BAD BOY 034-5039-00Dimensions:THICKNESS: 3/16"OVERALL LENGTH: 6-3/4"COIL LENGTH: 4-1/2"COIL DIAMETER: 1-1/8"CASE QTY: 40PALLET QTY: 100

Deck Idler Spring For Bad Boy

Deck Idler Spring replaces Bad Boy 034-9050-00.Replaces:BAD BOY 034-9050-00Dimensions:THICKNESS: 5/32"OVERALL LENGTH: 6-1/4"COIL LENGTH: 4-1/8"COIL DIAMETER: 1-1/4"CASE QTY: 40PALLET QTY: 100

Idler Return Spring

Idler Return Spring replaces Husqvarna/AYP 532169022, 169022.Replaces:AYP/ROPER/SEARS 532169022AYP/ROPER/SEARS 169022HUSQVARNA 532169022HUSQVARNA 169022Dimensions:DIAMETER: 1/2"LENGTH: 3-1/4"COIL LENGTH: 1-3/4"CASE QTY: 150PALLET QTY: 48

Plastic Deflector For Ayp

Plastic Deflector replaces AYP/Husqvarna 532 13 09-68, 130968, 139450, 171634, 171859, 532130968, 532139450, 532171859, 130968X418, 130968X428.Replaces:AYP/ROPER/SEARS 130968AYP/ROPER/SEARS 139450AYP/ROPER/SEARS 171634AYP/ROPER/SEARS...

Pump Belt Tensioner Spring For Scag

Pump Belt Tensioner Spring replaces Scag 483087. Fits Freedom Z models SFZ36, 48, 52 and 61, SMTC-48V, SMTC-52A, SMWC-52A and SMWC-52V, SMWC-61A, SMWC-61V, SPZ52 and 61 Patriot, STC-48A and STC-48V.Replaces:SCAG 483087Dimensions:OVERALL LENGTH:...

Secondary Deck Belt Tensioner Spring For Gravely

Secondary Deck Belt Tensioner Spring replaces Gravely 08300507. Old number 08334100. Fits models 890100, 890101, 890102, 915172, 915174, 915176, 915200, 915202, 915204, 915206, 915216.Replaces:GRAVELY 08300507GRAVELY 08334100Dimensions:OVERALL LENGTH:...

Pto Spring For Scag

PTO Spring replaces Scag 482667. Fits models STT61V-27KA Turf Tiger, STT61V29CH EFI Tiger Cat, SMT-72A Turf Tiger, SMT52A Turf Tiger and many more. Refer to your parts manual for correct application.Replaces:SCAG 482667Dimensions:OVERALL LENGTH:...

Drive Belt Tensioner Spring For Gravely

Drive Belt Tensioner Spring replaces Gravely 08300711. Fits models ZT HD 44, ZT HD 48, ZT HD 52, ZT HD 60, Pro-Turn 48, Pro-Turn 52, Pro-Turn 60, Pro-Turn ZX48, Pro-Turn ZX52, and Pro-Turn ZX60.Replaces:GRAVELY 08300711Dimensions:OVERALL LENGTH:...

Pump Drive Belt Tensioner Spring For Scag

Pump Drive Belt Tensioner Spring replaces Scag 484560. Fits Cheetah 48" and 52" cut.Replaces:SCAG 484560Dimensions:OVERALL LENGTH: 14"LENGTH OF COIL: 11.8000"WIRE DIAMETER: 0.2000"COIL DIAMETER: 1.0100"

Drive Belt Tensioner Spring For Exmark

Drive Belt Tensioner Spring replaces Exmark 116-6316. Fits models LZDS902K605, LZDS902K725, LZDS902DKU605A1, TTS481GKA48300, TTS541CKA48300, TTS600GKA523E0, TTX650EKC52400, TTX680PKC60400, TTX691GKA52400 and more.Replaces:EXMARK...

Deck Belt Tensioner Spring For Scag

Deck Belt Tensioner Spring replaces 483704. Fits Turf Tiger 52", 61" and 72" cut. Also fits Tiger Cat 61" and 72" cut.Replaces:SCAG 483704Dimensions:OVERALL LENGTH: 16"LENGTH OF COIL: 13"WIRE DIAMETER: 0.1870"COIL DIAMETER: 0.9750"

Deck Idler Spring For Scag

Right-hand Deck Idler Spring replaces Scag 483247. Fits Cheetah 48", Cheetah 52", Tiger Cub 48", 52", Wild Cat 48", Wild Cat 52".Replaces:SCAG 483247Dimensions:OVERALL LENGTH: 10"LENGTH OF COIL: 7.8000"WIRE DIAMETER: 0.1300"COIL DIAMETER: 1"

Deck Spring For Husqvarna

Deck Spring replaces Husqvarna 532401872. Used on Husqvarna, Poulan and Jonsered. Fits Husqvarna models LT2317CMA, LZ11577, P11577, LT2216, LT2213 and others. Fits Poulan models PB22H46YT, PB19546YT, PB30, PXT12530 and others. Fits Jonsered models...

Return Spring For Husqvarna

Return Spring replaces Husqvarna 532401971. Fits Husqvarna, Poulan models YT1942T, YTH2042, YTA18542, LT152, XT195H42LT, PB20H42LT, PB22H42YT, YTH22V42 and others. Fits Jonsered models LT2216, LT2217, LT2223 and others.Replaces:HUSQVARNA...

Deck Belt Spring

Mower Deck Drive Belt Tightner Spring for John Deere GX21582/GX20377. Fits models L120, L130, G110, 145, 155C, 190C, LA140, LA145, LA150, LA155, LA165, LA175, D140, D150, D155, D160, D170.Replaces:JOHN DEERE GX21582JOHN DEERE GX20377Dimensions:DIAMETER:...

Torsion Spring Deflector

Torsion Spring replaces Husqvarna / AYP 532123713, 106734, 149287, 532106734, 122713X, 123713, 53213713X.Replaces:AYP/ROPER/SEARS 532123713AYP/ROPER/SEARS 106734AYP/ROPER/SEARS 149287AYP/ROPER/SEARS 532106734AYP/ROPER/SEARS 123713XAYP/ROPER/SEARS...

Deck Belt Spring For Husqvarna

Deck Belt Spring replaces Husqvarna 596989801, old number 539120920. Fits Husqvarna Z, RZ and LSZ series machines. Fits Poulan 541ZX and 460ZX. Fits Jonsered models Z56R and Z54R.Replaces:HUSQVARNA 596989801HUSQVARNA 539120920Dimensions:OVERALL...

Extension Spring For Husqvarna

Extension Spring for deck drive replaces Husqvarna 532196105. Fits models LT2227A2, LT2323A2, PB22H48YT, PB22H54YT, PB24H48YT, PB24H54YT, PBGT22H48, SOGT22H48 and more.Replaces:HUSQVARNA 532196105Dimensions:OVERALL LENGTH: 7.3000"LENGTH OF COIL: 4...

Extension Spring For Exmark

Deck Belt Extension Spring replaces Exmark 1-603414. Fits models FMD524, FMD604, Lazer Z XP, Lazer Z HP, Phazer, Turf Ranger, Turf Tracer and more.Replaces:EXMARK 1-603414Dimensions:OVERALL LENGTH: 5.7500"LENGTH OF COIL: 3.4000"WIRE DIAMETER: 0...

Deck Wheel Hardware Kit

Exmark Anti Scalp Roller Hardware Kit used with Rotary 07-12018 Wheel Kit.Dimensions:CASE QTY: 60PALLET QTY: 60

Idler Arm Spring For Dixie Chopper

Idler Arm Spring replaces Dixie Chopper 10222.Replaces:DIXIE CHOPPER 10222Dimensions:LENGTH: 6-1/4"THICKNESS: 1/8"COIL LENGTH: 4-1/8"COIL DIAMETER: 7/8"CASE QTY: 75PALLET QTY: 100

Extension Spring For Murray

Extension Spring Replaces Murray 165X76SE.Replaces:MURRAY 165X76SEDimensions:THICKNESS: 1/8"LENGTH OF COIL: 4-1/4"COIL DIAMETER: 13/16"TOTAL LENGTH: 11-1/2"CASE QTY: 100PALLET QTY: 48

Extension Spring For Mtd

Extension Spring replaces MTD 732-0429A, 932-0429A. Fits Variable Speed Model 18 HP Tractors. Speed Selector Lever Spring.Replaces:MTD 732-0429AMTD 9320429ADimensions:OVERALL LENGTH: 4"COIL LENGTH: 2-1/2"COIL DIAMETER: 1/2"CASE QTY: 500PALLET QTY: 48

Extension Spring For Mtd

Extension Spring replaces MTD 932-0594A.Replaces:MTD 732-0594AMTD 932-0594ADimensions:THICKNESS: 1/8"LENGTH OF COIL: 5-11/16"COIL DIAMETER: 29/32"TOTAL LENGTH: 7-3/4"CASE QTY: 30PALLET QTY: 100

Belt Guide For Bobcat

Replaces Bobcat 32345-02. Used on Older Model Single Belt Variable Speed Mowers. Uses 2 on Engine Pulley & 4 on Wheel Drive Pulley. (6 per unit).Replaces:BOBCAT/RANSOMES 32345-02Dimensions:CASE QTY: 200PALLET QTY: 60

Wheel Drive Spring For Snapper

Wheel Drive Spring replaces Snapper 1-7326, 2-9025, 7029025, 7029025YP.Replaces:SNAPPER/KEES 1-7326SNAPPER/KEES 2-9025SNAPPER/KEES 7029025SNAPPER/KEES 7029025YPDimensions:DIAMETER: 5/8"THICKNESS: 1/16"OVERALL LENGTH: 3-1/4"LENGTH OF COIL: 1-1/2"CASE QTY:...
